UV resistant

Yes

Nominal cross sectional area of conductor

2.5

Core insulation material

Polyolefine

Core identification

Ziffern

Weight

345

Lead sheath

No

Drain wire

No

Nominal voltage U

1

Sheath colour

grau

Shape of conductor

rund

Conductor material

Kupfer

Sheath material

Polyvinylchlorid (PVC)

Conductor category

Kl.1 = eindrähtig

Laminated sheath

No

Fibre optic elements

No

Armouring/reinforcement

ohne

Permitted cable outer temperature during assembling/handling

0

Permitted cable outer temperature after assembling without vibration

-20

Number of pilot/reduced cores

0

Inner semi-conducting layer

No

Outer semi-conducting layer

No

Longitudinal water blocking screen

No

Nominal voltage U0

0.6

Screen

No

Number of cores

6

Longitudinal water blocking conductors

No

Suitable for underground installation

No

Concentric conductor

ohne

Cable width approx.

15

Cable height approx.

15

Low smoke according to IEC 61034-2

No

Max. conductor temperature

90

Protective barrier

ohne

Outer diameter approx.

14.8

With protective conductor

Yes

Rodent resistant

No

Conductor surface

blank

Radial water blocking cable

No

Reaction-to-fire according to EN 13501-6: Class

Dca

Reaction-to-fire according to EN 13501-6: Smoke production

s2

Reaction-to-fire according to EN 13501-6: Flaming droplets/particles

d2

Reaction-to-fire according to EN 13501-6: Acidity

a3

Min. permitted bending radius, stationary application/permanent installation

118

Specification core insulation

Polyethylen, vernetzt (VPE)

Sheath material specification

sonstige

Cable geometry

rund

Conductor resistance at 20 °C

7.41

Core identification according to HD 308 S2

Yes

Suitable as installation cable

Yes

Certified for shipboard application

No

Suitable as medium-voltage cable

No

Suitable as high-voltage cable

No

Certified as airport lighting cable

No

Circuit integrity according to EN 50200 annex E

No

Circuit integrity according to IEC 60331-1

ohne

Circuit integrity according to IEC 60331-2

ohne

Circuit integrity according to IEC 60331-3

ohne

Circuit integrity according to EN 50200

ohne

Circuit integrity according to BS 6387 CWZ

No

Circuit integrity according to BS 8434-2

No

Circuit integrity according to BS 8491

nein
