Current supply

Batterie

Measured value memory

No

Indication

digital

Measurement range selection

manuell/automatisch

TRMS measurement

Yes

Continuity test

Yes

Interface

No

Capacitance measurement

Yes

Temperature measurement

Yes

Frequency measurement

Yes

Sound level measurement (dB)

No

Data hold

Yes

Infrared Interface (IR)

No

Explosion-tested version

No

Analogue bar graph display

Yes

Bluetooth interface

No

Resistance (diode) test

Yes

Inductance measurement

No

Lowest resolution- DC voltage

0,1 mV

Lowest resolution- DC current

10 µA

Lowest resolution- AC voltage

0,1 mV

Lowest resolution- AC current

10 µA

Lowest resolution- Resistance

0,1 Ohm

Conductivity measurement

No

Max. voltage measuring range, AC

1000

Max. voltage measuring range, DC

1000

Max. current measuring range, AC

10

Max. current measuring range, DC

10

Max. resistance measuring range

50

Maximum value storage

Yes

Multiple display

No

Circuit category measurement

CAT IV

Min. value storage

Yes

Nominal test voltage 100 V

No

Nominal test voltage 1000 V

No

Nominal test voltage 250 V

No

Nominal test voltage 500 V

No

Relative value measurement

No

Peak value memory

No

Duty cycle measurements

No

Temperature measurement

Yes

Max. temperature measuring range

400

Lowest resolution- Temperature

0,1 °C

Max. capacitance measuring range

9999

Lowest resolution- Capacitance

0,001 µF

Max. frequency measuring range

99.99

Lowest resolution- Frequency

0,01 Hz

Analogue bargraph display analogue/logarithmical

Yes

Low resistance measurement (4-wire Kelvin connection)

No

Temperature measurement RTD

No

Temperature measurement TC

Yes

Nominal test voltage 10 V

No

Nominal test voltage 50 V

No

Cable length measurement

No

Cable symmetry testing for two wire connections a-b-E

No

Power and energy measurement

No

Harmonics analysis/power quality analysis

No

Rotational speed measurement

No

Automatic circuit breaker

No

Max. voltage measuring circuit category

600

With display backlight

Yes

Scaling bar graph linear

Yes

Scaling bar graph logarithmic

No

High voltage test for motor windings

No
